Fly
Download media
Object number2012.00990
TitleFly
CreatorChapelle (draughtsman)
DescriptionSchooner Fly. Lines plan (sheer plan, half breadth plan and body plan) and profile. Includes dimensions.
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueblueprint
Dimensions
- height: 480 mm
width: 990 mm
