The Fairmile 'F' Type - M.G.2001

Add to selection

Object number2012.00843

TitleThe Fairmile 'F' Type - M.G.2001

Creator John Lambert (draughtsman)‎

DescriptionThe Fairmile 'F' Type - M.G.2001. General arrangement (deck plan annd profile) and lines plan (sheer plan, half breadth plan and body plans). Includes technical specifications.

Production date 1991-04-02 - 1991-04-02

Object nameship plan

Object categorytechnical drawing

Materialtracing film

Techniquemechanical copy

Dimensions
