Chaperon

Add to selection

Object number2012.00034.3

TitleChaperon

CreatorModel Shipways (producer)‎, John A. Braynaert (draughtsman)‎

DescriptionSteamer Chaperon. Lines plan (sheer plan, half breadth plan and body plan) and perspective drawings of details. Scale 1/8 inch to 1 foot.

Object nameship plan

Materialpaper

Techniqueprinted

Dimensions
