Challenge
Download media
Object number2012.00020
TitleChallenge
Creator H.W. Potter (draughtsman)
DescriptionGreat Lakes schooner Challenge. Lines plan (sheer plan, half breadth plan and body plan), general arrangement (deck plan and profile) and rigging details.
Production date 1944-05 - 1944-05
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueblueprint
Dimensions
- height: 620 mm
width: 890 mm
