Challenge
Download media
Object number2012.00008
TitleChallenge
CreatorChapelle
DescriptionClipper ship Challenge. Lines plan (sheer plan, half breadth plan and body plan). Scale 1/4 inch to 1 foot. Includes technical specifications.
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 270 mm
width: 600 mm
