Arrow
Download media
Object number2011.1135
TitleArrow
CreatorAdmiralty
DescriptionCutter Arrow. Lines plan (half breadth plan and body plan), profile and midship section. Includes technical specifications.
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 470 mm
width: 600 mm
