Ariel / Sir Lancelot
Download media
Object number2011.1107
TitleAriel / Sir Lancelot
Creator David MacGregor (draughtsman)
DescriptionTea clippers Ariel and Sir Lancelot. Lines plan (sheer plan, half breadth plan and body plan). Scale 1/8 inch to 1 foot. Includes technical specifications.
Production date 1952 - 1952
Object nameship plan
Object categorytechnical drawing
Materialtracing film
Techniquemechanical copy
Dimensions
- height: 380 mm
width: 770 mm
