Annandale
Download media
Object number2011.1020
TitleAnnandale
Creator David MacGregor (draughtsman)
DescriptionClipper ship Annandale. Lines plan (sheer plan, half breadth plan and body plan) and midship section. Scale 3/16 inch to 1 foot. Taken from builder's half model.
Production date 1964-02 - 1964-02
Object nameship plan
Object categorytechnical drawing
Materialtracing paper
Techniquedrawn
Dimensions
- height: 600 mm
width: 1350 mm
