Ann Miln

Add to selection

Download mediaDownload media

Object number2011.1018

TitleAnn Miln

Creator David MacGregor (draughtsman)‎

DescriptionClipper ship Ann McKim. Lines plan (sheer plan, half breadth plan and body plan). Annotated by David MacGregor. Draft drawing, taken from model in Ward Road Museum, Dundee. Scale 3/8 inch to 1 foot.

Production date 1961-05 - 1961-05

Object nameship plan

Object categorytechnical drawing

Materialtracing paper

Techniquedrawn

Dimensions
