Ann McKim
Download media
Object number2011.1015
TitleAnn McKim
CreatorChapelle (draughtsman), Smithsonian Institution
DescriptionClipper ship Ann McKim. Lines plan (sheer plan, half breadth plan and body plan). Includes technical specifications.
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueblueprint
Dimensions
- height: 480 mm
width: 1450 mm
