Ann Duthie

Add to selection

Object number2011.1003

TitleAnn Duthie

Creator James Henderson (draughtsman)‎

DescriptionShip Ann Duthie. Lines plan (sheer plan, half breadth plan and body plan). Scale 3/6 inch to 1 foot. Lines taken of builder's half model.

Production date 1972-05 - 1972-05

Object nameship plan

Techniquedrawn

Dimensions
