TitleAngelita
Creator David MacGregor (draughtsman)
DescriptionSchooner Angelita. General arrangement (deck plan and profile), lines plan (sheer plan, half breadth and body plan), sail and rigging plan. Scale 1/4 inch to 1 foot.
Production date 1984-05 - 1984-05
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedrawn
Dimensions
- height: 640 mm
width: 1070 mm
