America
Download media
Object number2011.0966
TitleAmerica
Creator G.F. Campbell (draughtsman), Model Shipways
DescriptionSchooner yacht America. Lines plan (half breadth plan, sheer plan and body plan), general arrangement (deck plan and profile) and deck details. Includes technical specifications.
Production date 1967-03 - 1967-03
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueprinted
Dimensions
- height: 530 mm
width: 710 mm
