Acbar
Download media
Object number2011.0938
TitleAcbar
CreatorAdmiralty
DescriptionShip Acbar. Profile, half breath plan and body plan. Includes technical specifications.
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 530 mm
width: 1600 mm
