Auxiliary Knockabout Ketch
Download media
Object number2013.04241
TitleAuxiliary Knockabout Ketch
Creator John G. Alden (draughtsman)
DescriptionAuxiliary Knockabout Ketch. General arrangement (profile, deck plan) and cross-section showing layout of cabin. Scale 3/4 inch to 1 foot.
Production placeBoston
Production date 1928-01-28 - 1928-01-28
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 620 mm
width: 1050 mm
