Ship of 500 Tons
Download media
Object number2013.03980
TitleShip of 500 Tons
Creator P. Hedderwick (draughtsman), W. Ballantine (printer)
DescriptionShip of 500 Tons. Lines plan (sheer plan, half-breadth plan, body plan) and general arrangement (profile, half-deck plan). Includes dimensions.
Production placeEdinburgh
Production date 1830 - 1830
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 310 mm
width: 410 mm
