Miltiades
Download media
Object number2013.03907
TitleMiltiades
Creator F.A. Smith (draughtsman)
DescriptionIron Ship Miltiades. General arrangement (profile, deck plan), lines plan (sheer plan, half-breadth plan, body plan) and midship section. Includes dimensions and historical notes.
Production date 2000-07 - 2000-07
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 295 mm
width: 390 mm
