1836 New Measurement Tonnage

Add to selection

Object number2013.03880

Title1836 New Measurement Tonnage

Creator David MacGregor (draughtsman)‎

Description1836 New Measurement Tonnage. Profile and cross-sections of unnamed ship, with chain-dotted line indicating tonnage length and dotted lines indicating how the deck was divided into six lengths. Drawing not to scale.

Production placeLiverpool

Object nameship plan

Object categorytechnical drawing

Materialtracing film

Techniquemechanical copy

Dimensions
