Spanish Frigate of 545 tons
Download media
Object number2013.03854
TitleSpanish Frigate of 545 tons
Creator Adrian Capt. Small (draughtsman)
DescriptionSpanish Frigate of 545 tons. Sail and rigging plan (profile). Includes dimensions. Text in Spanish.
Production placeBrixham
Production date 1967-08 - 1967-08
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 460 mm
width: 620 mm
