Castle Class Corvettes, Ship Nos.343-345.
Download media
Object number2013.03649
TitleCastle Class Corvettes, Ship Nos.343-345.
Creator Caledon Shipbuilders Ltd. Robb (shipbuilder)
DescriptionCastle Class Lengthened Single Screw Corvettes, Ship Nos.343-345. General arrangement (inboard profile, plans of compass platform, bridge deck and forecastle deck). Scale 1/8 inch to 1 foot. Shipbuilders stamp mark "Robb Caledon Shipbuilders Ltd" in upper left of plan.
Production placeLeith
Production date 1972-09-08 - 1972-09-08
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 580 mm
width: 925 mm
