Working Model of Steam Tug
Download media
Object number2013.03472
TitleWorking Model of Steam Tug
Creator Harold A. Underhill (draughtsman), Son & Ferguson Ltd. Brown (printer and distributor)
DescriptionWorking Model of Steam Tug. General arrangement (profile, deck plan), stern and bow elevations. Scale 1 inch to 5 feet.
Production placeGlasgow
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 560 mm
width: 915 mm
