Victory 43
Download media
Object number2013.03311
TitleVictory 43
Creator John Hunt (draughtsman)
DescriptionMotor Sailer Victory 43. Provisional lines plan (sheer plan, half-breadth plan, body plan). Scale 1:20.
Production placeSittingbourne
Production date 1982 - 1982
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 560 mm
width: 1000 mm
