Object number2013.03288
TitleVenta
Creator A.G. Smith (draughtsman)
DescriptionSailing Barge Venta. General arrangement (profile, deck plan), lines plan (sheer plan, half-breadth plan, body plan) and hull sections. Includes dimensions. Scale 1/4 inch to 1 foot.
Production date 1967 - 1967
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 650 mm
width: 975 mm
