Ship of 400 Tons
Download media
Object number2013.00892
TitleShip of 400 Tons
Creator P. Hedderwick (draughtsman), W. Ballantine (printer)
DescriptionShip of 400 Tons. Lines plan (sheer plan, half-breadth plan, body plan) and general arrangement (profile, deck plan showing beams) and stern view. Includes dimensions.
Production placeEdinburgh
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 665 mm
width: 960 mm
