Schooner of 104 Tons
Download media
Object number2013.00868
TitleSchooner of 104 Tons
Creator W. Ballantine (printer)
DescriptionSchooner of 104 Tons for Deep Sea Fishery. Lines plan (sheer plan, half-breadth plan, body plan), deck plan, cross section and details of sliding keels. Includes dimensions.
Production placeEdinburgh
Production date 1829 - 1829
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 500 mm
width: 730 mm
