Steam Packet of 258 Tons

Add to selection

Object number2013.00727

TitleSteam Packet of 258 Tons

Creator P. Hedderwick (draughtsman)‎, W. Ballantine (printer)‎

DescriptionSteam Packet of 258 Tons. Lines plan (sheer plan, half-breadth plan, body plan), deck plan, longitudinal section, half cross-sections of engine room and boilers. Includes dimensions.

Production placeEdinburgh

Production date 1830 - 1830

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquephotographed

Dimensions
