Smack of 173 Tons
Download media
Object number2013.00535
TitleSmack of 173 Tons
Creator P. Hedderwick (draughtsman), W. Ballantine (printer)
DescriptionSmack of 173 Tons. Lines plan (sheer plan, half-breadth plan, body plan) and deck plan. Includes dimensions.Scale 1/4 inch to 1 foot. Annotated.
Production placeEdinburgh
Production date 1830 - 1830
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 480 mm
width: 660 mm
