Ship of 500 Tons
Download media
Object number2013.00382
TitleShip of 500 Tons
Creator P. Hedderwick (draughtsman), W. Ballantine (printer)
DescriptionShip of 500 Tons. Lines plan (sheer plan, half-breadth plan, body plan) and general arrangement (profile, half-deck plan). Includes dimensions.
Production placeEdinburgh
Production date 1830 - 1830
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotocopy
Dimensions
- height: 665 mm
width: 960 mm
