Loch Class Frigates Nos.342 and 346-350
Download media
Object number2013.00353
TitleLoch Class Frigates Nos.342 and 346-350
Creator Caledon Shipbuilders Ltd. Robb (shipbuilder)
DescriptionLoch Class Frigates Nos.342 and 346-350. General arrangement (plans of superstructure and bridge decks, port side and starboard elevations of bulkhead and bulwark). Scale 1/2 inch to 1 foot. Includes tables of supply items. "Robb Caledon Shipbuilders Ltd" and David MacGregor Plans stamp marks in upper left section of plan.
Production placeLeith
Production date 1972-09-08 - 1972-09-08
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 725 mm
width: 2460 mm
