Royal Katherine

Add to selection

Object number2012.05690.4

TitleRoyal Katherine

Creator Helmut Breisinger (producer)‎, H. Schwall (draughtsman)‎

DescriptionShip modelling plan for the 84-gun Royal Navy Ship of the Line Royal Katherine. Lines plan (sheer plan, half-breadth plan, body plan) and section. Scale 1:75.

Production placeMetzingen, Karlsruhe

Production date 1966 - 1966

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquedyeline

Dimensions
