Royal Katherine

Add to selection

Object number2012.05690.3

TitleRoyal Katherine

Creator Helmut Breisinger (producer)‎, H. Schwall (draughtsman)‎

DescriptionShip modelling plan for the 84-gun Royal Navy Ship of the Line Royal Katherine. Sail and rigging plan showing front and back views and details of masts, sails and rigging equipment. Also includes colour and painting guide. Scale 1:75.

Production placeMetzingen, Karlsruhe

Production date 1966 - 1966

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquedyeline

Dimensions
