Merchant Ship of 330 Tons
Download media
Object number2012.05507
TitleMerchant Ship of 330 Tons
Creator Penelope Steel (publisher)
DescriptionMerchant Ship of 330 Tons. Profile, lines plan (sheer plan, half-breadth plan, body plan) and stern elevation. Includes dimensions.
Production placeLondon
Production date 1805-08-31 - 1805-08-31
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueprinted
Dimensions
- height: 295 mm
width: 840 mm
