Pequod (ex Hispaniola)
Download media
Object number2012.05287
TitlePequod (ex Hispaniola)
Creator Ltd Andrews Engineering Co. (shipbuilder)
DescriptionPequod. General arrangement (profile, deck plan) of aftbody of vessel, showing layout of engine room . Also includes lines plan (body plan). Scale 1/2 inch to 1 foot. Stamp mark for "Andrews Engineering Co., Ltd.".
Production placeHull
Production date 1954-04-12 - 1954-04-12
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 695 mm
width: 1120 mm
