Loch Class Frigates Nos.342 and 346-350
Download media
Object number2012.05037
TitleLoch Class Frigates Nos.342 and 346-350
Creator Caledon Shipbuilders Ltd. Robb (shipbuilder)
DescriptionLoch Class Frigates Nos.342 and 346-350. General arrangement (deck plan) of forecastle and upper deck, including plans of superstructure deck and oerlikon gun platform. Scale 1/4 inch to 1 foot. "Robb Caledon Shipbuilders Ltd" and David MacGregor Plans stamp marks in upper left section of plan.
Production placeLeith
Production date 1972-09-08 - 1972-09-08
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 700 mm
width: 2300 mm
