Loch Class Frigates Nos.342 and 346-350

Add to selection

Object number2012.05036

TitleLoch Class Frigates Nos.342 and 346-350

Creator Caledon Shipbuilders Ltd. Robb (shipbuilder)‎

DescriptionLoch Class Frigates Nos.342 and 346-350. General arrangement (deck plan) of lower deck. Scale 1/4 inch to 1 foot. "Robb Caledon Shipbuilders Ltd" stamp mark in upper left section of plan.

Production placeLeith

Production date 1972-09-08 - 1972-09-08

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquedyeline

Dimensions
