Merchant Ship of 347 Tons
Download media
Object number2012.04690
TitleMerchant Ship of 347 Tons
Creator P. Hedderwick (draughtsman), C. Thomson (engraver)
DescriptionMerchant Ship of 347 Tons. Lines plan (sheer plan, half-breadth plan, body plan) and deck plan, showing upper deck beams. Annotated.
Production placeEdinburgh
Production date 1830 - 1830
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 430 mm
width: 540 mm
