Isabella
Download media
Object number2012.04687
TitleIsabella
Creator J. Richardson (publisher)
DescriptionIsabella. Lines plan (sheer plan, half-breadth plan, body plan) and detail of stern.
Production placeHull
Production date 1833-08 - 1833-08
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquephotographed
Dimensions
- height: 455 mm
width: 860 mm
