Hope

Add to selection

Object number2012.04654

TitleHope

Creator P. Hedderwick (draughtsman)‎, W. Ballantine (printer)‎

DescriptionFast Sailing Brig Hope. Lines plan (sheer plan, half-breadth plan, body plan), profile, deck plan, midship section and perpendicular view of stern. Includes hull dimensions.

Production placeEdinburgh

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquephotographed

Dimensions

DocumentationTreatise on Marine Architecture, Containing the Theory and Practice of Shipbuilding, with Rules for the Proportions of Masts, Rigging, Weight of Anchors, &c.
