Forward
Download media
Object number2012.04651
TitleForward
Creator H.N. Leask (draughtsman)
DescriptionGun Brig Forward. Lines plan (sheer plan, half-breadth plan, body plan), profile and general arrangement (inboard works, half-deck plan). 1/4 inch to 1 foot.
Production placeLiverpool
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueblueprint
Dimensions
- height: 575 mm
width: 660 mm
