Longboat for 80-Gun Ship
Download media
Object number2012.04540
TitleLongboat for 80-Gun Ship
CreatorSteel & Co (publisher)
Description32 foot Longboat for 80-gun ship. Profile, half-deck plan and lines plan (sheer plan, half-breadth plan, body plan). Scale 1/4 inch to 1 foot. Includes dimensions.
Production placeLondon
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 200 mm
width: 345 mm
