Ship's Boats: Launch/Pinnace/Cutter/Yawl

Add to selection

Object number2012.04537

TitleShip's Boats: Launch/Pinnace/Cutter/Yawl

CreatorSteel & Co (publisher)‎

DescriptionShip's Boats: Lines plans (sheer plan, half-breadth plan, body plan) for 30 foot Launch, 28 foot Pinnace, 30 foot Eight-oared Cutter and 26 foot Yawl. Includes section plan for Yawl. Scale 1/4 inch to 1 foot.

Production placeLondon

Production date 1805 - 1805

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquedyeline

Dimensions
