Mary

Add to selection

Download mediaDownload media

Object number2012.04610

TitleMary

Creator P. Hedderwick (draughtsman)‎, W.H. Lizars (engraver)‎

DescriptionBrig Mary. Lines plan (sheer plan, half-breadth plan, body plan) and deck plan, showing framing. Includes dimensions. Scale 1/4 inch to 1 foot.

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquephotocopy

Dimensions
