Juan de La Vega
Download media
Object number2012.04188
TitleJuan de La Vega
Creator James Henderson (draughtsman)
DescriptionClipper Brigantine Juan de La Vega. Lines plan (sheer plan, half-breadth plan, body plan). Scale 1/4 inch to 1 foot.
Production placeAberdeen
Production date 1959-08-28 - 1959-08-28
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniquedyeline
Dimensions
- height: 195 mm
width: 510 mm
