James Baines

Add to selection

Object number2012.04140

TitleJames Baines

Creator Massachusetts Institute of Technology Hart Nautical Museum

DescriptionClipper Ship James Baines. Lines plan (sheer plan, half-breadth plan, body plan) and sail plan (profile). Includes information on ship's dimensions, tonnage and sail measurements. Scale 1/16 inch to 1 foot.

Production placeCambridge, MA

Object nameship plan

Object categorytechnical drawing

Materialpaper

Techniquephotographed

Dimensions
