74 Gun Ship of the Line
Download media
Object number2012.04040
Title74 Gun Ship of the Line
Creator Penelope Steel (publisher)
Description74 Gun Ship Ship of the Line. Lines plan (sheer plan, half-breadth plan, body plan) and view of stern. Scale 1/8 inch to 1 foot.
Production placeLondon
Production date 1805-08-31 - 1805-08-31
Object nameship plan
Object categorytechnical drawing
Materialpaper
Techniqueprinted
Dimensions
- height: 295 mm
width: 840 mm
