Notes and calculations relating to the chains of the Clifton Suspension Bridge
Download media
Object numberDM162/8/2/4/folio 7
TitleNotes and calculations relating to the chains of the Clifton Suspension Bridge
Creator Isambard Kingdom Brunel (author)
DescriptionNotes and calculations relating to the Clifton Suspension Bridge: measurements of the chains at the centre and extremities and notes and calculations relating to strain and friction.
Production date 1838-11-17 - 1838-11-17
Object namenotebook sheet
Object categorypersonal record
Materialpaper
Techniquehand-written
Dimensions
- height: 330 mm
width: 210 mm
Credit lineBy Courtesy of the Brunel Institute – a collaboration of the ss Great Britain Trust and the University of Bristol
